People who hijack any situation to talk about how they 'use Arch' like some sort of preacher has become a wildly popular Meme in Geek culture, however not without reason. Here I go: I've been using Arch for about four years now and I have to say I truly love it!

I've been introduced to Linux about 13 years ago through Ubuntu and immediately I knew this would be my OS of choice. During my early Linux years I've been testing out tons and tons of distributions and Desktop Environments. I eventually settled for Debian and stayed there for a bunch of years.

Since everone was always raving about Arch Linux I became very curious to try it out but time and again I was intimidated by the installation procedure. Until one day I just decided to back-up all the things! <insert meme> and go for bust. Guess what... it worked! It booted the first-time round! However this was without LUKS encryption and EFI boot which I always encourage and love to use.

After piecing and splicing together multiple tutorials I finally had the perfect installation procedure down to a science. This install will give you a EFI bootable image secured by LUKS full-disk (partition) ecnryption. I will keep this updated continually since I myself also still use this as my cheat sheet from time to time.

Prerequisites

Check internet connection

ping -c 3 www.google.com

If needed try connecting via WiFi

iwctl
device list
station connect <DEVICE> <SSID>

Check EFI vars present

ls /sys/firmware/efi/efivars

Main installation

Set system time using NTP:

timedatectl set-ntp true
timedatectl status

Partitioning

TIP: If dual-booting leave a 128MiB empty ‘gap’ partition in between your ‘other os’ and your new partition.

Zap all data on disk and create a new GPT table.

Show current partition table

lsblk

NOTE: X represents your drive mountpoint. mine is sda.

gdisk /dev/sdX

o # Create a new empty GUID partition table (GPT)
y # Confirm

EFI System Partition (ESP)
n # Add a new partition
1 # Partition number
[Return] # First sector
+512M # Last sector = size
ef00 # Partition type = EFI System

LUKS container
n # Add a new partition
2 # Partition number
[Return] # First sector
[Return] # Last sector = Use remaining space
8e00 # Partition type = Linux LVM

p # Check partitions
w # Write changes to disk and exit
y # Confirm

Format EFI System Partition (ESP):

mkfs.fat -F32 /dev/sda1

Encrypt the other partition with LUKS (512 Bit AES-XTS and SHA512 for passphrase):

cryptsetup luksFormat -v -s 512 -h sha512 /dev/sda2
cryptsetup luksOpen /dev/sda2 luks

Setup Logical Volume Manager:

pvcreate /dev/mapper/luks
vgcreate rootvg /dev/mapper/luks

Create Logical Volumes:

lvcreate -n swap -L 4G -C y rootvg
lvcreate -n root -L 25G rootvg
lvcreate -n home -l 100%FREE rootvg

Check LVM Setup:

pvs
vgs
lvs

Create filesystems for LVs:

mkfs.ext4 /dev/mapper/rootvg-home
mkfs.ext4 /dev/mapper/rootvg-root
mkswap /dev/mapper/rootvg-swap
swapon /dev/mapper/rootvg-swap

Mount LVs and ESP for installation:

mount /dev/mapper/rootvg-root /mnt
mkdir /mnt/boot
mkdir /mnt/home
mount /dev/mapper/rootvg-home /mnt/home
mount /dev/sda1 /mnt/boot

Selecting fastest mirrors

reflector --country France --country Germany --age 12 --protocol https --sort rate --save /etc/pacman.d/mirrorlist

Install base system

pacstrap /mnt base base-devel linux linux-firmware

Generate fstab (make sure swapon is set when running these)

genfstab -U /mnt >> /mnt/etc/fstab
nano /mnt/etc/fstab (for SSD change swap line from ‘defaults’ to ‘defaults,discard’)

Mount into system

arch-chroot /mnt

Install some basic packages

pacman -S lvm2 vim nano

Set hostname

echo arch-laptop > /etc/hostname

Set timezone

ln -sf /usr/share/zoneinfo/Europe/Amsterdam /etc/localtime
hwclock --systohc

Locales

nano /etc/locale.gen

Uncomment the following two locales
en_US.UTF-8 UTF-8
en_US ISO-8859-1

locale-gen

Set Language

echo LANG=en_US.UTF-8 > /etc/locale.conf
export LANG=en_US.UTF-8

Enabling the AUR repo

nano /etc/pacman.conf

Add these lines at the bottom of the file:
[archlinuxfr]
SigLevel = Never
Server = https://repo.archlinux.fr/$arch

After saving be sure to update your sources:

pacman -Sy

User Management

Set root password

passwd

Create user:

useradd -m -g users -G wheel,storage,power -s /bin/bash <user>
passwd <user>

Setup sudoers:

EDITOR=nano visudo

Uncomment this line:
%wheel ALL=(ALL) ALL

Add to the bottom:
Defaults rootpw

Installing some basic software

Bash completion:

pacman -S bash-completion

Install packages for WiFi:

pacman -S dialog wpa_supplicant wpa_actiond rfkill

Find and enable your wireless-interface

ip link
systemctl enable netctl-auto@<YOUR_INTERFACE>

Installing the bootloader:

bootctl install

Write long UUID to file for later use

blkid | grep sda2 | cut -f2 -d\" >> /boot/loader/entries/arch.conf

Create an entry for Arch

nano /boot/loader/entries/arch.conf

title Arch Linux
linux /vmlinuz-linux
initrd /initramfs-linux.img
options cryptdevice=UUID=<YOUR_UUID>:rootvg:allow-discards root=/dev/mapper/rootvg-root rw

Install Intel Microcode:

This is useful for when you want to be able to receive firmware updates to your CPU.
You should only follow this step if you run on a Intel CPU.

pacman -S intel-ucode

Add the following to your previously created boot entry:
initrd /intel-ucode.img

nano /boot/loader/entries/arch.conf

Your final boot entry should look like this:
title Arch Linux
linux /vmlinuz-linux
initrd /intel-ucode.img
initrd /initramfs-linux.img
options cryptdevice=UUID=<YOUR_UUID>:rootvg:allow-discards root=/dev/mapper/rootvg-root rw

Set required hooks for boot init.

in /etc/mkinitcpio.conf make sure the following hooks are present, if not add them:
encrypt
lvm2

An example of a complete string of hooks would be:
base udev autodetect modconf block filesystems keyboard encrypt lvm2 fsck

mkinitcpio -p linux

Finalize:

exit
umount -R /mnt
reboot

Congratulations! You are now booted into your new Arch system. As you've noticed things are a little 'texty' out here. Let's add some paint.


Install a graphics driver and display server

sudo pacman -S mesa xorg-server xorg-xinit xorg-twm xorg-xclock

Install awesome GUI stuff

sudo pacman -S gnome gdm gnome-tweaks chrome-gnome-shell gnome-keyring
sudo systemctl enable gdm.service

Installing a AUR helper

In Arch we have a great asset that is the Arch User Respository (AUR). Here we can find all kinds of user maintained packages build-scripts that would otherwise be quite hard to install. Using an AUR helper makes installing packages from the AUR as easy as Pacman for instance. Let's install my favorite one, Yay!

git clone https://aur.archlinux.org/yay.git
cd yay && makepkg -si

Installing and enabling a Firewall

sudo pacman -S ufw
sudo ufw enable

Installing and enabling OpenSSH-Server

sudo pacman -S openssh
sudo systemctl enable --now sshd.service

If needed make sure the SSH connection get's through the Firewall

sudo ufw allow 22

Enable NetworkManager

sudo pacman -S networkmanager networkmanager-openvpn
sudo systemctl enable NetworkManager.service

Install some funky themes

sudo pacman -S adapta-gtk-theme
yay -S paper-icon-theme-git

Install some awesome packages

sudo pacman -S file-roller vlc vim git keepassxc reflector jdk8-openjdk

Add a Mozilla signature in order to build Firefox

gpg --recv-key 0x61B7B526D98F0353
yay -S firefox-nightly

Install some support libraries

sudo pacman -S xdotool xsel udisks2 dosfstools exfat-utils ntfs-3g

Enable minimal media codecs

sudo pacman -S gstreamer gst-plugins-good gst-plugins-ugly

After install stuff [Optional]:

Install some nifty little package installers (Flatpak vs Snap.. FIGHT!)

sudo pacman -S flatpak
yay -S snapd

Pacman hooks

Install a Pacman hook to update the mirrorlist to specified criterea upon upgrading the pacman-mirrorlist package.

sudo mkdir -p /etc/pacman.d/hooks

Create a new file in /etc/pacman.d/hooks/mirrorupgrade.hook and paste the following code:

[Trigger]
Operation = Upgrade
Type = Package
Target = pacman-mirrorlist

[Action]
Description = Updating pacman-mirrorlist with reflector and removing pacnew...
When = PostTransaction
Depends = reflector
Exec = /usr/bin/env sh -c "reflector --country 'Netherlands' --latest 10 --protocol https --age 12 --sort rate --save /etc/pacman.d/mirrorlist; if [[ -f /etc/pacman.d/mirrorlist.pacnew ]]; then rm /etc/pacman.d/mirrorlist.pacnew; fi"

Now every time the pacman-mirrorlist package gets upgraded (ie. new mirrors get added) we use reflector to test the mirror speed and protocol to obtain a new ordered mirrorlist.

NOTE: The above script depends on reflector so be sure to have it installed as described above.

Terminal preference

See the zsh n00b guide

Auto mounting of /media/data and /media/games.

First make the folders to mount to:

sudo mkdir -p /media/data
sudo mkdir -p /media/games

Find the proper UUIDs:

sudo blkid | grep sdb1
sudo blkid | grep sdc1

Then add the UUID of desired drive to the fstab like so:

UUID=<your-uuid> /media/data ext4 defaults 0 1
UUID=<your-uuid> /media/games ntfs-3g defaults,discard 0 1

Installing steam native runtime:

sudo pacman -S steam steam-native-runtime

Troubleshooting

Use NetworkManager instead of netctl

During installation we enabled the netctl-auto configuration in order to have access to wireless internet post-install. This is because life after install is just a terminal prompt. After installing a GUI though you probably would like to start using a graphical network manager. In this case we're going to assume you installed GNOME.

sudo systemctl disable netctl-auto@<YOUR_INTERFACE>.service
sudo systemctl enable --now NetworkManager.service

Simply reboot and enjoy your new NetworkManager


DOCUMENT HISTORY:

12-01-2021

Removed advise for proprietary Macbook video driver and optimized some commands.

14-01-2020

I swapped out aurman in favor of yay since Aurman is not that well supported anymore by the developer(s). Updated the references accordinlgy.

12-12-2018

I no longer recommend to install the synaptics-touch driver since the built-in support now exceeds the performance and configuration options of the third-party integration. It just gets in the way of libinput.

More logical bundling of package installations and some more consistent use of code blocks. One command per block is my stride.

12-04-2018

I no longer encourage the use of MultiLib.

Added a step to fetch and install the Aurman signature.

09-25-2018

  • Added useful Pacman hook for testing the new entries in pacman-mirrorlist according to predefined criterea. Credits: Tead.

08-23-2018

Swapped out Yaourt in favor of Aurman. It is no longer recommended to use Yaourt as your package manager since it hasn't received updates or security review in a very long time.

Added document history for transparency sake.
